SMARTebox Batt (SMARTsensor)

Remote monitoring of drinking water and sewage networks

The SMARTebox Batt is an IoT solution for remote reading of flow meters, pressure sensors, alarm contacts for remote reading and anomaly detection of large consumers and drinking distribution networks. In addition, leak points can be identified by monitoring the pressure. The data logger is battery operated and waterproof and is compatible with all instruments present in the water networks. Thanks to the cellular connection via LTE-M and NBIOT, the SMARTebox Batt offers monitoring of decentralized and underground systems. If the signal in the shaft is strongly attenuated, an external antenna can optionally be used.

The transmission of data and integrity is guaranteed via the Telekom PSA certified transmission path into the IoT platform. The data can be read from any operator system via the open REST API of the IoT platform.

Technical Features

• Battery power supply via 6 x standard C-cell 15,000 mAh
• 4 x pulse inputs for consumption meters
• 2 x 4…20mA inputs for third-party pressure sensors
• Alarm and fault contact
• Waterproof housing
• Remote configuration via IoT platform
• REST API for connecting to the operator system
• WebApp for commissioning the sensors
